Material: Body: ASTM A351 CF8M (SS 316)
Ball: ASTM A351 CF8M (SS 316)
Cap (tube end): ASTM A351 CF3M (SS316L)
Seat: PTFE
Typical Application
· Clean dry air system (CDA)
· Oil free air system (OFA)
· Inert bulk gas distribution
· Process cooling water (PCW)
· Utility Nitrogen system (UN2)
· Process vacuum exhaust
· Bulk chemical delivery Breathable air Service
Features
· Tube-end for orbital welding
· Swing-out 3pcs design for easy field maintenance
· Double PE bagged
· Lower cost
Specification
· Pressure Rating: Vacuum to 50 bar
· Operating temperature: -40oC to 150 oC
· Inner Surface: BA (25 Ra)
· Pneumatic Actuators optional
· 6” & 8” sizes available
|
