1/2”~1” High Flow Pressure Regulators
Material:
Body: SS316/SS316L / SS316L VAR
Diaphragm: SS316L / Hastelloy C-22
Seat: PCTFE / Vespel / Teflon
Typical Application
· For Hook-up system
· For special gas system
· For bulk gas system
Features
· Wetted materials are corrosion resistant
· ； High flow capacity
· Low & High Pressure Capability
· Various connections for choice
Specification
· Maximum Inlet Pressure: up to 3500 psi
· Outlet Pressure: 0~200 psi
· Operating temperature: -40oF to 350 oF
· Helium leakage test (In board): 1x10-9 scc/sec
· Flow Range: 0-1200 SLPM
· Porting: 2P, 3P, 4P
· Inner surface: EP (10 Ra / 5 Ra)； BA(Oil Free)
|
