Applications: Ultra high vacuum butterfly valve is used to put through or cut off the airflow in vacuum pipeline. Applicable medium can be pure air and noncorrosive gases Technical Data: Fluid:gas、water、stream、acid liquid more Leak rate:≤1.0×10-7Pa·L/s; Operating pressure:1.0×10-7Pa~1.6×106pa; Working temp.:-50℃~+150℃;-50℃~+250℃; Materials: SS304、SS316L Sealing element::VITON、Cuprum PipeConnection:flange Figure Structure:
|
